APC Smart UPS 2200VA, 1980W, USB, Serial RM 2U 230V (SUA2200RMI2U)

Đơn giá (VND):

1,900,000 + VAT

Mã hàng: SUA2200RMI2U

Thông tin nhanh về sản phẩm

UPS ĐÃ QUA SỬ DỤNG, CHƯA BAO GỒM ẮC QUY
Bảo hành trọn bộ 12 tháng khi mua kèm ắc quy.

SUA2200RMI2U
APC Smart-UPS 2200VA/ 1980W, USB & Serial, Rackmount 2U, 230V

THÔNG TIN THAY THẾ ẮC QUY CHO UPS (UPS BATTERY REPLACEMENT)
Tên & số lượng bộ ắc quy lắp trong UPS (Internal battery cartridge name & quantity)	APCRBC43 x 01
Bộ sạc của UPS (UPS charger)	48VDC/ 169W
Bộ ắc quy lắp trong UPS (Internal battery pack)	=48VDC =2x 4x 12Vx 5Ah =480VAh =8 bình, mắc thành 2 chuỗi 48VDC//.
Tủ ắc quy mở rộng (External (extended) battery cabinet)
Thời gian sạc lại (Typical recharge time)	3+ giờ, tùy thuộc vào dung lượng (Ah) hoặc Công suất (W) của ắc quy.
Ắc quy khuyến nghị thay thế cho UPS (Recommended replacement battery)	WP5-12		WPL5-12

Sản phẩm tương tự

APC Smart-UPS 1000VA/670W, Tower, USB & Serial, 230V (SUA1000I)

APC Smart-UPS 1000VA/670W, Tower, USB & Serial, 230V (SUA1000I)

Đơn giá (VND): 1,200,000 ^{+ VAT}

Mã hàng: SUA1000I

APC Smart UPS 1500VA/ 980W, USB, Serial 230V (SUA1500I)

APC Smart UPS 1500VA/ 980W, USB, Serial 230V (SUA1500I)

Đơn giá (VND): 1,790,000 ^{+ VAT}

Mã hàng: SUA1500I

APC Smart-UPS 1500VA, 980W, USB & Serial RM 2U 230V (SUA1500RMI2U)

APC Smart-UPS 1500VA, 980W, USB & Serial RM 2U 230V (SUA1500RMI2U)

Đơn giá (VND): 1,790,000 ^{+ VAT}

Mã hàng: SUA1500RMI2U

APC Smart UPS 1000VA/ 670W, USB Serial, RM 2U, 230V (SUA1000RMI2U)

APC Smart UPS 1000VA/ 670W, USB Serial, RM 2U, 230V (SUA1000RMI2U)

Đơn giá (VND): 1,200,000 ^{+ VAT}

Mã hàng: SUA1000RMI2U

APC Smart UPS 5000VA/4000W, 230V Tower/ Rackmount 5U (SUA5000RMI5U)

APC Smart UPS 5000VA/4000W, 230V Tower/ Rackmount 5U (SUA5000RMI5U)

Đơn giá (VND): 5,900,000 ^{+ VAT}

Mã hàng: SUA5000RMI5U

APC Smart UPS 2200VA, 1980W, USB, Serial 230V (SUA2200I)

APC Smart UPS 2200VA, 1980W, USB, Serial 230V (SUA2200I)

Đơn giá (VND): 1,900,000 ^{+ VAT}

Mã hàng: SUA2200I

APC Smart UPS 3000VA, 2700W, USB, Serial RM 2U 230V (SUA3000RMI2U)

APC Smart UPS 3000VA, 2700W, USB, Serial RM 2U 230V (SUA3000RMI2U)

Đơn giá (VND): 2,990,000 ^{+ VAT}

Mã hàng: SUA3000RMI2U

APC Smart-UPS 3000VA, 2700W, USB & Serial 230V (SUA3000I)

APC Smart-UPS 3000VA, 2700W, USB & Serial 230V (SUA3000I)

Đơn giá (VND): 2,990,000 ^{+ VAT}

Mã hàng: SUA3000I

APC Smart-UPS 750VA/480W USB & Serial 230V (SUA750I)

APC Smart-UPS 750VA/480W USB & Serial 230V (SUA750I)

Đơn giá (VND): Liên hệ

Mã hàng: SUA750I

APC Smart-UPS 1500VA 230V UL Approved (SUA1500IX38)

APC Smart-UPS 1500VA 230V UL Approved (SUA1500IX38)

Đơn giá (VND): Liên hệ

Mã hàng: SUA1500IX38

APC Smart-UPS XL 2200VA USB & Serial 230V No Battery (SUA2200UXI)

APC Smart-UPS XL 2200VA USB & Serial 230V No Battery (SUA2200UXI)

Đơn giá (VND): Liên hệ

Mã hàng: SUA2200UXI

APC Smart-UPS XL 2200VA/1980W RM 3U 230V (SUA2200RMXLI3U)

APC Smart-UPS XL 2200VA/1980W RM 3U 230V (SUA2200RMXLI3U)

Đơn giá (VND): Liên hệ

Mã hàng: SUA2200RMXLI3U

APC Smart-UPS XL 3000VA USB & Serial 230V No Battery (SUA3000UXI)

APC Smart-UPS XL 3000VA USB & Serial 230V No Battery (SUA3000UXI)

Đơn giá (VND): Liên hệ

Mã hàng: SUA3000UXI

APC Smart-UPS XL 1000VA USB & Serial 230V No Battery (SUA1000UXI)

APC Smart-UPS XL 1000VA USB & Serial 230V No Battery (SUA1000UXI)

Đơn giá (VND): Liên hệ

Mã hàng: SUA1000UXI

APC Smart-UPS XL Battery Pack Tower/Rack Convertible 48V, rackmount with kit, 5U (SUA48XLBP)

APC Smart-UPS XL Battery Pack Tower/Rack Convertible 48V, rackmount with kit, 5U (SUA48XLBP)

Đơn giá (VND): Liên hệ

Mã hàng: SUA48XLBP

APC Smart-UPS 750VA/480W USB RM 2U 230V (SUA750RMI2U)

APC Smart-UPS 750VA/480W USB RM 2U 230V (SUA750RMI2U)

Đơn giá (VND): Liên hệ

Mã hàng: SUA750RMI2U

APC Smart-UPS XL 750VA/480W USB & Serial 230V (SUA750XLI)

APC Smart-UPS XL 750VA/480W USB & Serial 230V (SUA750XLI)

Đơn giá (VND): Liên hệ

Mã hàng: SUA750XLI

APC Smart-UPS XL Battery Pack 48V, rackmount, 3U (SUA48RMXLBP; SUA48RMXLBP3U)

APC Smart-UPS XL Battery Pack 48V, rackmount, 3U (SUA48RMXLBP; SUA48RMXLBP3U)

Đơn giá (VND): Liên hệ

Mã hàng: SUA48RMXLBP; SUA48RMXLBP3U

APC Smart-UPS XL 3000VA Rack/Tower Convertible Network Package for Wiring Closets (SUA3000XLI)

APC Smart-UPS XL 3000VA Rack/Tower Convertible Network Package for Wiring Closets (SUA3000XLI)

Đơn giá (VND): Liên hệ

Mã hàng: SUA3000XLI

Thông số kỹ thuật

Output

Output Power Capacity

1980 Watts / 2200 VA

Max Configurable Power

1980 Watts / 2200 VA

Nominal Output Voltage

230V

Output Voltage Note

Configurable for 220 : 230 or 240 nominal output voltage

Output Voltage Distortion

Less than 5% at full load

Output Frequency (sync to mains)

47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal

Topology

Line Interactive

Waveform Type

Sine wave

Output Connections

(8) IEC 320 C13
(1) IEC 320 C19
(2) IEC Jumpers

Input

Nominal Input Voltage

230V

Input Frequency

50/60 Hz +/- 3 Hz (auto sensing)

Input Connections

IEC-320 C20
Schuko CEE 7 / EU1-16P
British BS1363A

Input voltage range for main operations

160 - 286V

Input voltage adjustable range for mains operation

151 - 302V

Batteries & Runtime

Battery Type

Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time

3 hour(s)

Replacement Battery

RBC43

RBC™ Quantity

1

Runtime Graph

Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.

Communications & Management

Interface Port(s)

DB-9 RS-232, SmartSlot, USB

Available SmartSlot™ Interface Quantity

1

Control panel

LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators

Audible Alarm

Alarm when on battery : distinctive low battery alarm : configurable delays

Emergency Power Off (EPO)

Có

Surge Protection and Filtering

Surge energy rating

480 Joules

Filtering

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height

89.00 mm

Maximum Width

483.00 mm

Maximum Depth

660.00 mm

Rack Height

2U

Net Weight

43.64 KG

Shipping Weight

51.50 KG

Shipping Height

260.00 mm

Shipping Width

600.00 mm

Shipping Depth

980.00 mm

Master Carton Units

1.00

Color

Black

Units per Pallet

8.00

Environmental

Operating Environment

0 - 40 °C

Operating Relative Humidity

0 - 95%

Operating Elevation

0-3000 meters

Storage Temperature

-15 - 45 °C

Storage Relative Humidity

0 - 95%

Storage Elevation

0-15000 meters

Audible noise at 1 meter from surface of unit

47.00 dBA

Online Thermal Dissipation

300.00 BTU/hr

Conformance

Regulatory Approvals

C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE

Sustainable Offer Status

RoHS

Compliant

PEP

Available in Documentation tab

EOLI

Available in Documentation tab

Other Environmental Compliance

China RoHS
